Application:Railway railroad, highway, cross-sea bridge, municipal elevated etc.
Beam characteristics:
Single-box single-chamber, single-box multi-chamber, curved beams, twisted beams, etc.
Wuxin features
01 Design capacity
Optimize the structural design, use three-dimensional modeling, simulate the combination of each formwork after the mold state, use of working conditions, demolding state, comprehensive consideration of the layout of the construction area and supporting equipment, combined with the total construction period and the specific construction period, the rationalization of the configuration of the corresponding type and number of formworks, to ensure that the construction at the same time to reduce the investment in the project.
02 Product Performance:Segmental beam core technology system
Bottom mold technology
-
Matching girder section anti-tipping technology
-
Matching beams intelligently control one-touch adjustment techniques that
-
Variable-height girder section bottom mold height stepless adjustment technology
-
Automatic longitudinal shift and anti-deviation technology for bottom-molded trolleys
End-mold technology
-
Precision Molding Technology for Prestressing Orifices
-
Prestressing anchor channel formwork sharing and blocking techniques
-
The technology of sharing end molds and internal molds for multiple sections of full girder sections
Internal mold technology
-
Hydraulic control technology to prevent downward deflection of any section of the front end of the inner mold
-
No-open-hole internal mold support technology for long line prefabricated jump section construction
-
The technology of sharing end molds and internal molds for multiple sections of full girder sections
External modeling techniques
-
Outer mold 3-D adjustment technology
-
The technology of fast and precise reset of the outer mold
-
Rapid disassembly and positioning technology for baffle molds
Integration of technologies
-
Flexible lap stopping technique for matching surfaces
-
Integral molding technology of Segmental girders for navigable holes
-
The technique of integral molding of curved surfaces of twisted beam segments
03 Production and lead time
Current record: 54 sets of section beam formworks, including standard, large-span, twisted beams of 3 major types and each type has a variety of different combinations of the use of the project, the formworks were produced in 2 months, and the assembly was finished in 1 month.
04 Service Force
1. We have our own professional installation engineer service team. With suitable conditions in site, each set of formwork installation takes only 7-10 days.
2. After the formwork is delivered for use, the theoretical + practical training for on-site construction personnel, the sections need to be interchanged between the tooth block, movable block and other parts of the technology and on-site briefings.
3. The use of the process, the company organizes the relevant technology, sales, after-sales personnel to visit regularly.
Special technology utilization
According to the specific beam type and characteristics of the project to optimize the configuration of formwork, in order to reduce the input of formwork, to help customers save costs.
